Overhead console lights are erratic-- FIXED

My 89 Grand Wagoneer with overhead console acted up today. There is something wrong with the overhead light circuit from what I can tell. Here is what is going on:

- The two courtesy lights near the front doors work fine
- The reading lights (both front set and rear set, as well as the cargo light) will NOT turn on if the courtesy lights are on (and the rear reading lamps as well as the dome light act as a courtesy along with the front two bulbs when the door is open)
- If I hold in the door jamb switch/shut the door, I can get ONE of the lights to come on, but very dimly. If I try to turn another one on, they all dim out.
- If I turn the cargo lamp switch to ON, none of the lights will come on.
- The vanity lamps on the visor will also dim if I try to turn on a reading lamp when they are on and vice versa.
- If I remove the cargo light bulb, NONE of the lights in this circuit will come on.

I'm not really that experienced with electronics, but it seems like the circuit may be starved of power. I've pulled all the door jamb switches, but no luck.

I've been using this wiring diagram to look for problems, but I am not good at reading them:
http://oljeep.com/gw/elec/90_numeric...8W_Page-24.jpg

I know that this diagram is from a 1990, but I am assuming that they are the same (since the 88's didn't have overhead consoles). Any ideas on what to check out?

Last edited by dflocks80 : 10-25-2009 at 12:59 PM.
Reply With Quote
  #2
Old 10-24-2009, 07:30 PM
dflocks80's Avatar
dflocks80 dflocks80 is offline
Member

Join Date: Feb 21, 2009
Location: Fuquay-Varina, NC
Posts: 129
Alright, so I broke bad and vacuumed out the Wagoneer tonight. Lo and behold, the lights came back on! I was pretty happy about this. Anyway, I went to spray Frebreeze on the carpet to freshen it up, and I shut the door. When I opened it back up, they went off again...

Anyway, it has been raining here both last night and all day today (which is when the problem occured) so my theory is as follows:

Something is getting wet that isn't supposed to be. I dried it up when I vacuumed, but I re-wet it with the Frebreeze. Does this sound plausible?
Reply With Quote
  #3
Old 10-24-2009, 08:21 PM
silvercert silvercert is offline
Gear Head

Join Date: Feb 05, 2009
Location: Goldsboro NC
Posts: 707
This is so weird that you posted this. I have been slowly putting my interior in and today got to the headliner. The only thing I did was remove covers and bulbs. I put all new bulbs in today and hooked everything back up and it stayed on with no key (very dim). The same things you listed are happening to me.
Reply With Quote
  #4
Old 10-25-2009, 12:13 AM
dflocks80's Avatar
dflocks80 dflocks80 is offline
Member

Join Date: Feb 21, 2009
Location: Fuquay-Varina, NC
Posts: 129
The lights are back on and working again, but I went out and bought some Damprid to dry the inside of it out (my windshield always fogs on the inside for no reason...?). Hopefully the moisture is the problem.

Silvercert, you may just need to vacuum yours out. Failing overhead lights may be a factory feature to let you know that your interior is dirty.
Reply With Quote
  #5
Old 10-25-2009, 01:05 PM
silvercert silvercert is offline
Gear Head

Join Date: Feb 05, 2009
Location: Goldsboro NC
Posts: 707
I think im covered with the cleaning part...lol

Reply With Quote
  #6
Old 10-25-2009, 02:21 PM
benztechnc's Avatar
benztechnc benztechnc is offline
232 I6

Join Date: Mar 02, 2009
Location: Raleigh, NC
Posts: 243
It sounds like you both are having wiring shorts. where two wires are touching in the harness somewhere. I would start with a simple ohm meter, and the wiring diagram, printed version. Wiring is very overwhelming but you just have to be patient.
__________________
-josh.
1978 jeep j-10 "Rusty" 4.2L/258ci t-18/dana 20 soa 33in BFGoorich a/t's and not running.--mine no longer...

http://s278.photobucket.com/albums/k...view=slideshow

2002 jeep Wrangler "T.J." (D.D.)

2000 Honda 929RR "Bumblebee" (TRASHED 12/24/09)
--latest project!

Raleigh NC.
Reply With Quote
  #7
Old 10-25-2009, 02:28 PM
710 Burner's Avatar
710 Burner 710 Burner is offline

Join Date: Jul 30, 2003
Location: Normal, Oklahoma
Posts: 8,684
Sounds like a bad ground to me.
__________________
Mark B. Jones

Quote:
Originally Posted by GrandWag&Prix
Actually, now that I think about it, that could be either awesome or really terrible.


'79 Cherokee Chief "Junaluska"
Reply With Quote
  #8
Old 10-25-2009, 05:27 PM
mdill's Avatar
mdill mdill is offline
Gone. Not Forgotten.

Join Date: Nov 22, 2000
Location: Richfield MN
Posts: 7,076
The lights have power all the time, the door switches provide ground to turn them on, sounds more like cruddy contacts or a pinched grounded wire to the door or dash switch.

Mike D.
Reply With Quote
  #9
Old 11-29-2009, 11:12 PM
dflocks80's Avatar
dflocks80 dflocks80 is offline
Member

Join Date: Feb 21, 2009
Location: Fuquay-Varina, NC
Posts: 129
I permanently fixed this problem about a week ago, so I thought I would post it in case someone runs into this problem later on. Anyway, my cowl drains were backed up, so I had water coming in my air vents and going under my carpet (fixing that is my current project). When I was pulling back the carpet to dry up the floorboard, I noticed the lights were flickering. I saw two plugs under the carpet near the driver's seat. One of the plugs connects 4 wires (a black, pink, orange/black, and dark blue/white if memory serves me correctly). Anyway, the plug was so badly corroded from the water that two of the wires fell out when I moved it.

I cut out the plug, and a few butt-connectors and jumpers later, I was back in business. Now, if I can fix the cowl problem (which I am almost done with), this problem shouldn't ever come back.
__________________
1989 Grand Wagoneer "Waggs"
  • Stock 360 and 727
  • Single piped Flowmaster 40 (with plugged AIR holes on manifold and heat riser valve wired open)
Leaks oil, needs a lift, but is mechanically sound.
Reply With Quote
  #10
Old 11-29-2009, 11:38 PM
jdaniel83's Avatar
jdaniel83 jdaniel83 is offline
Master Mechanic

Join Date: Sep 26, 2008
Location: Texas
Posts: 928
Glad to see you got it fixed. I am having a similar problem, among others, with my '89 GW so I am going to check that connection myself. Thanks.
__________________
'89 GW; 4" Susp Lift on 32" Wild Country MTX; 360, HEI, Edelbrock Intake, Melling MTA-1 Cam, Summit 600 carb, 3.73 Gears

'70 Wagoneer; stock Buick Dauntless 350, TH400; 3.73 stock gears

'83 Wagoneer Limited; stock 360, 727, 3.31 gears.
Reply With Quote
  #11
Old 11-30-2009, 12:13 PM
aatcman's Avatar
aatcman aatcman is offline
258 I6

Join Date: Apr 10, 2006
Location: Norfolk, VA
Posts: 281
X3

Thanks for the tip -- I've been having strange issues with my interior lights -- which have gotten progressively worse -- I think I'll be looking for that connector as well.

Thanks!!
__________________
Just my 2 Cents (Good grief!! Even my weedeater laughs at me now!! Silly gas prices!)

1986 Grand Wagoneer (225xxx)

1988 Comanche Pioneer (215xxx)
Reply With Quote
  #12
Old 11-30-2009, 02:35 PM
grand_wag_85's Avatar
grand_wag_85 grand_wag_85 is offline
Murphy's Law Poster Child

Join Date: Dec 03, 2003
Posts: 10,710
One of my old ones was just like that. Turns out the PO wired the key on power wire to one of the wires for the wipers. Took me forever to figure out why it only came on every now and then. In his defense both wires were white with a black stripe and ran side by side.
__________________
You know it's bad when your car's on the EPA's 10 most wanted list!

'82 J10
'65 J2000

Reply With Quote
  #13
Old 10-06-2010, 02:33 PM
jsmorris's Avatar
jsmorris jsmorris is offline
Member

Join Date: Feb 03, 2010
Location: West Central Indiana
Posts: 101
Thumbs up

X4!

I've been looking around trying to find someone else with this problem. My lights do exactly what you stated in the first post. I was trying to get ahold of a wiring schematic before I start taking things apart, but the dim lights made me thing that there is a serious resistance in the current flow somewhere, not really a short because that would provide a path of no or low resistance but I still have some voltage making it to the bulbs like you did.

Now that I think about it, I have not checked into the cowl drain AND I noticed last week when I put new parking brake cables on that the hole where the line passes through the floor board doesn't have any seal around the cable...? Not sure where to get a seal, but I might just put some silicon on it and call it a day.
__________________
Joel Morris
'89 Grand Wagoneer
Reply With Quote
  #14
Old 10-17-2010, 09:58 AM
jsmorris's Avatar
jsmorris jsmorris is offline
Member

Join Date: Feb 03, 2010
Location: West Central Indiana
Posts: 101
I did notice that my front set of map lights on the console do not come on with the interior switch on the dash nor with a door opened, though they do work individually with their own switches. I assume there are separate wires for these lights with the door curcuit, the dash switch circuit, and the circuit that provides power for its own switch at the light?

The rear map lights and the rear dome light all work with the doors and the dash switch, so I assume the front map lights should as well.
__________________
Joel Morris
'89 Grand Wagoneer
